Product Details

Overview

We designed Ember to be the most efficient high speed camera ever. It’s small, light, and insanely fun to use. Ember is unique in that it can record continuous high speed footage with no ram based clip limit since it records directly to a 4TB internal SSD or to external media with our Media Expander.

Freefly is now a proud member of the L-Mount Alliance! This camera ships with L-Mount already installed and ready to work with L-Mount lenses out of the box.

Shooting high speed is now just like shooting anything else, push record to start and stop, and Ember captures everything to solid state memory - as simple... as that.

The Ember app for iOS means you can go from capture to sharing in seconds.

• Check out these (untreated) sample clips shot with Ember.

Features

• 5K max resolution at 600fps
• 4K 800fps (936fps with 3.0 firmware)
• Active L-Mount
• 4TB internal SSD
• External Media Options (Media Expander)
• Gpixel sensor
• Fast iOS based app workflow
• Apple ProRes Codec
• Global Shutter
• Wireless Control
• USB 3.2 Type C

*Actual formatted data capacity of 4TB drive is 3,980GB

Technical Specs

• Sensor - S35 Gpixel
• Recording Modes
  • Color - 5K, 4K, 3K, 2K
  • Mono - 2.5K, 2K
• Codec - 10-bit Apple ProRes
• Lens Mount
  • L-Mount
• 4 TB Drive Option:
  • Maximum shooting capacity for Ember
  • Actual formatted data capacity - 3,980 GB / 3.98 TB
  • Capture Time (max):
    • 5120 × 2880, 600 fps - 36 min (1,296,000 frames, 15 hrs of playback at 24 fps)
    • 4096 × 2160, 800 fps - 45 min (2,160,000 frames, 25 hrs of playback at 24 fps)
• Weight
  • Body with L-Mount - 781 g / 25.55 oz
• Dimensions
  • With L-Mount - 100 × 104 × 88 mm (WHD) / 3.94 × 4.09 × 3.46 in (WHD)
• Full specs here

In the Box

• Qty 1 - Ember S5K camera body with internal 4TB SSD
• Qty 1 - Active L-Mount, pre-installed
• Qty 1 - USB PD to XT30 Adapter (20V)
• Qty 1 - XT30 to 4-pin Microfit Power Cable (5')
• Qty 1 - USB C-C 3.0 Cable (3')
• Qty 1 - D-Tap-Ember Power Cable (6")
• Qty 1 - Rear accessory mount stand-offs (pair)
• Qty 8 - M3 x 10mm SHCS fasteners for accessory mounts

Compatibility

• With included L-Mount
• L-Mount lenses, with or without electronic internals
• L-Mount lenses with internal motors can be manually controlled (iris/focus) by Ember through camera, iOS/macOS app, and HTTP API (coming soon)
• Alternate Lens Mounts
• Freefly Active EF Mount
• KipperTie Revolva FE/PL
• KipperTie Adapta FE/PL-LW
• C7 Adapters (Non-Electronic: M, EF, RF, Nikon, FD, PL, LPL)
• Ember S2.5K accessories from Freefly - Highlights:
• Media Expander - adds external SSD media interface and SDI output
• External SSD - 4TB for maximum storage, 1.28TB or 2.56TB for Pre-record function
• Cheese Plate Plus - for mounting several options of external battery plates.
• Dual Voltage AC Power supply - For shore power while shooting or offloading footage

Support
